    FOIF 1000m Reflectorless ARM9 Core FOIF RTS-102R10 Total Station With USB/RS-232C/Bluetooths Optional

    Ask Lasest Price
    Brand Name : FOIF
    Model Number : RTS-102R10
    Certification : CE
    Price : Negotiable
    Supply Ability : 1000 pieces per year
    • Product Details
    • Company Profile

    FOIF 1000m Reflectorless ARM9 Core FOIF RTS-102R10 Total Station With USB/RS-232C/Bluetooths Optional

    FOIF 1000m reflectorless ARM9 Core FOIF RTS-102R10 total station with USB/RS-232C/Bluetooths optional

    FOIF 1000m Reflectorless ARM9 Core FOIF RTS-102R10 Total Station With USB/RS-232C/Bluetooths OptionalFOIF 1000m Reflectorless ARM9 Core FOIF RTS-102R10 Total Station With USB/RS-232C/Bluetooths OptionalFOIF 1000m Reflectorless ARM9 Core FOIF RTS-102R10 Total Station With USB/RS-232C/Bluetooths OptionalFOIF 1000m Reflectorless ARM9 Core FOIF RTS-102R10 Total Station With USB/RS-232C/Bluetooths OptionalFOIF 1000m Reflectorless ARM9 Core FOIF RTS-102R10 Total Station With USB/RS-232C/Bluetooths Optional

    ModelRTS-102R10
    Telescope
    Length/Image156mm/Erect
    Objective apertureφ45mm
    Magnification30x
    Field of view1°30’
    Shortest focus distance1.0m
    Angle measurement
    Reading systemAbsolute encoder
    Angle unit360/400gon/6400mil,selectable
    Display resolution0.5"/1"/5"(0.1mgon/0.2mgon/1mgon)
    Accuracy2"
    Distance measurement(R500)
    Display resolution(m/inch) selectable0.1mm/1mm
    Laser class prismClass1
    Reflector /Reflective sheetClass3R
    Measurement range (Good condition)
    Reflectorless1 to 600m
    Reflective sheet/RP601 to 800m
    Single prism1 to 5000m
    Accuracy
    Prism2mm+2ppm
    Reflective sheet/RP603mm+2ppm
    Reflectorless1-200m: 3mm+2ppm/>=200m:5mm+3ppm
    Measuring timeInitial : 2s
    Prism(Standard model)3s
    Reflective sheet/RP60(Standard model)3s
    Reflectorless(Standard model)3s
    Level vial sensitivity
    Plate level vial30" /2mm
    Circular level vial8' /2mm
    CompensatorDual-axis compensator
    Working range3'
    Setting accuracy1"
    Laser plummet(Standard)
    Accuracy±1mm/1.5m
    Laser classClass 2/ IEC60825-1
    Laser brightnessAdjustable
    Laser wave length635nm
    Display
    LCD, 6lines X2Ocharacters(96 X160 dots )
    Power
    Battery3400mAh Li-ion Rechargeable
    Output voltage7.4V DC
    Continuous operation time8 hours
    (Single distance measurement every 30 seconds
    ChargerFDJ6-LI9 (100V / 240V)
    Charging time ( at +20℃)Approx. 4 hours
    Application programs
    Data collection/Stake out/Resection/REM/MLM/Point to line
    AREA/Z coordinate/OFFset/3D Road/Traverse adjustment
    Tape measurement/Section/Axis postioning measurement
    Others
    CPUARM9 Core
    Memory4G internal memory
    SensorsBuilt-in temperature and pressure sensors
    KeyboardAlphanumerical key board, both sides
    Weight(including batteries)9.0kg
    InterfaceUSB/RS-232C/Bluetooth(Optional)
    Water and dust protectionIP54 (IEC60529)
    Packaging & Shipping


    Economical 2


    Our Services

    1. Warranty: 12 months warranty is offered for survey equipment. 6 months warranty offered for survey accessory. Warranty comes in effective from the day your receive good.
    2. Repair in warranty: We are responsible for supplying new parts for repairing. Round way freight will be charged by us. If it is necessary, product will be required to send back to our service center to be repaired, round way freight is charged by us. Our engineer will repair in your office for special case.
    3. Repair out of warranty: We will offer related parts at commercial cost. Freight will be shared by us
    4. Training and calibration: Our engineer is qualified for training and calibration for GNSS and Total Station on site. We offer this service to bulk order while customer has requirement.
    5. Technical support is offered 24/365.
