Description & Features:
The Trimble® DiNi® Digital Level is a digital height measurement sensor designed for any job site where fast and accurate height determination is required. Use the Trimble DiNi for applications such as precise leveling of flat and sloping surfaces, establishing the vertical component of grade and ground profiles, subsidence monitoring, and establishing the vertical component of control networks.
The Trimble DiNi Digital Level lets you:
1. Determine accurate height information 60% faster than with automatic leveling
2. Eliminate errors and reduce rework with digital readings
3. Transfer data to the office easily
4. Measure to a field of just 30 cm
The easy-to-use and accurate Trimble DiNi offers numerous features to maximize your productivity in the field.
Specification:
| TRIMBLE DINI03 DIGITAL LEVEL |
| PERFORMANCE |
| Accuracy DIN 18723, standard deviation height measuring per 1 km (3280.84 ft) of double leveling |
| Trimble DiNi 0.3 mm per km |
| Electronic measurement | Invar precision bar code staff | 0.3 mm (0.001 ft) |
| Standard bar code staff | 1.0 mm (0.004 ft) |
| Visual measurement | 1.5 mm (0.005 ft) |
| Distance measurement with a 20 m (65.62 ft) sighting distance | Invar precision bar code staff | 20 mm (0.066 ft) |
| Standard bar code staff | 25 mm (0.082 ft) |
| Visual measurements | 0.2 m (0.656 ft) |
| Trimble DiNi 0.7 mm per km |
| Electronic measurement | Invar precision bar code staff | 0.7 mm (0.066 ft) |
| Standard bar code staff | 1.3 mm (0.082 ft) |
| Visual measurements | 2.0 m (0.656 ft) |
| Distance measurement with a 20 m (65.62 ft) sighting distance | Invar precision bar code staff | 25 mm (0.066 ft) |
| Standard bar code staff | 30 mm (0.082 ft) |
| Visual measurements | 0.3 m (0.656 ft) |
| Range |
| Electronic measurement | 1.5 m–100 m (4.92 ft–328.08 ft) |
| Visual measurement | from 1.3 m (4.265 ft) |
| Electronic Measurement |
| Trimble DiNi 0.3 mm per km |
| Electronic measurement | Resolution height measurement | 0.01 mm / 0.0001 ft / 0.0001 in |
| Resolution distance measurement | 1 mm (0.003 ft) |
| Measurement time. | 3 s |
| Trimble DiNi 0.7 mm per km |
| Electronic measurement | Resolution height measurement | 0.1 mm / 0.001 ft / 0.001 in |
| Resolution distance measurement | 10 mm (0.033 ft) |
| Measurement time. | 2 s |
| Horizontal Circle |
| Type of graduation | 400 grads and 360 deg |
| Graduation interval | 1 grad and 1deg |
| Estimation to | 0.1 grad and 0.1 deg |
| Measurement Programs: Trimble DiNi 0.3 mm per km |
| Standard programs | Single measurement with and without stationing, stakeout, line leveling with intermediate sight and stakeout, line adjustment |
| Leveling methods¹ | BF,BFFB, BFBF, BBFF, FBBF aBF, aBFFB, aBFBF, aBBFF, aFBBF |
| GENERAL SPECIFICATION |
| TELESCOPE | Aperture | 40 mm (0.131 ft) |
| Field of view at 100 m. | 2.2 m (7.217 ft) |
| Electronic measurement field | 0.3 m (0.984 ft) |
| Magnification | Trimble DiNi 0.3 mm per km | 32 x |
| Trimble DiNi 0.7 mm per km | 26 x |
| Compensator |
| Inclination range | ±15' |
| Setting accuracy | Trimble DiNi 0.3 mm per km | ±0.2" |
| Trimble DiNi 0.7 mm per km | ±0.5" |
| Circular level | 8'/2 mm with Illumination |
| Display | Graphical, 240 x 160 pixels, monochrome with illumination |
| Keyboard | 19-key alpha-numeric and 4-way arrow key for navigation |
| Recording | Internal memory | up to 30 000 data lines |
| External memory | USB Flash Drive support |
| Data transfer | USB Interface for data transfer between DiNi and PC (means two way communication) |
| Real-time clock and temperature sensor | Trimble DiNi 0.3 mm per km | Recording of time or temperature |
| Trimble DiNi 0.7 mm per km | N.A. |
| Power supply | Internal battery | Li-Ion, 7.4 V / 2.4 Ah |
| | Operating time | 3 days working time without illumination |
| Weight (including battery) | 3.5 kg (7.72 lb) |
