    IP68 Magnesium Alloy Material Hi-Target V200 GPS RTK GNSS With Linux Operating System

    Ask Lasest Price
    Brand Name : Hi Target
    Model Number : V200
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 10pcs/day
    Delivery Time : 5-10day
    • Product Details
    • Company Profile

    IP68 Magnesium Alloy Material Hi-Target V200 GPS RTK GNSS With Linux Operating System

    Product Description

    IP68 magnesium alloy material Hi-Target V200 GPS RTK GNSS with Linux operating system .

    IP68 Magnesium Alloy Material Hi-Target V200 GPS RTK GNSS With Linux Operating SystemIP68 Magnesium Alloy Material Hi-Target V200 GPS RTK GNSS With Linux Operating System

    IP68 Magnesium Alloy Material Hi-Target V200 GPS RTK GNSS With Linux Operating System

    IP68 Magnesium Alloy Material Hi-Target V200 GPS RTK GNSS With Linux Operating SystemIP68 Magnesium Alloy Material Hi-Target V200 GPS RTK GNSS With Linux Operating SystemIP68 Magnesium Alloy Material Hi-Target V200 GPS RTK GNSS With Linux Operating SystemIP68 Magnesium Alloy Material Hi-Target V200 GPS RTK GNSS With Linux Operating System

    IP68 Magnesium Alloy Material Hi-Target V200 GPS RTK GNSS With Linux Operating System

    IP68 Magnesium Alloy Material Hi-Target V200 GPS RTK GNSS With Linux Operating SystemIP68 Magnesium Alloy Material Hi-Target V200 GPS RTK GNSS With Linux Operating System


    Specification

    RTK V200 technical parameters
    GNSS configurationNumber of channels: 800+
    BDS: B1, B2, B3
    GPS: L1, L2, L5
    GLONASS: L1, L2
    GALILIEO: E1, E5a, E5b
    SBAS: Support
    QZSS: Support
    Output formatASCII: NMEA-0183, binary code
    Positioning output frequency1Hz~20Hz
    Static data formatGNS, Rinex dual format static data
    Difference formatCMR, RTCM2.X, RTCM3.0, RTCM3.2
    Network modeVRS, FKP, MAC; support NTRIP protocol
    System Configurationoperating systemLinux operating system
    Start Time3 seconds
    data storageBuilt-in 8GB ROM, supports automatic storage of static data
    Accuracy and reliability [1]RTK positioning accuracyPlane: ±(8+1×10-6D) mm (D is the distance between the measured points)
    Elevation: ±(15+1×10-6D) mm (D is the distance between the measured points)
    Static positioning accuracyPlane: ±(2.5+0.5×10-6D) mm (D is the distance between the measured points)
    Elevation: ±(5+0.5×10-6D) mm (D is the distance between the measured points)
    DGPS positioning accuracyPlane accuracy: ±0.25m+1ppm; elevation accuracy: ±0.50m+1ppm
    SBAS positioning accuracy0.5m
    Initialization time<10 seconds
    Initialization reliability>99.99%
    Communication unitI/O portUSB Type-C interface, SMA interface
    Built-in 4G network communicationBuilt-in eSIM4 card, including 3 years Internet access fee, you can connect to the Internet after power on
    WiFi communication802.11 a/b/g/n access point and client mode, can provide WiFi hotspot service
    blue tooth communicationblue tooth® 4.2/2.1+EDR, 2.4GHz
    Built-in radioBuilt-in transceiver station:
    Power: 0.5W/1W/2W adjustable
    Frequency band: 410MHz~470MHz
    Protocol: HI-TARGET, TRIMTALK450S, TRIMMARKⅢ, TRANSEOT, SOUTH, CHC
    Number of channels: 116 (16 of which can be configured)
    sensorElectronic bubbleRealize smart alignment
    Tilt measurementBuilt-in high-precision inertial navigation, automatic attitude compensation, 8mm+0.7mm/°tilt (accuracy within 30°<2.5cm)
    User InterfacebuttonA power button
    LED indicator lightSatellite lights, signal lights, power lights
    WEB UIBuilt-in WEB page to realize receiver setting and status check
    Function applicationAdvanced FeaturesOTG function, NFC IGRS, WebUI interaction, U disk firmware upgrade
    Smart applicationSmart base station, smart voice, function self-check, smart CORS
    Remote ServiceNews push, online upgrade, remote control
    cloud serviceEquipment management, location services, collaborative operations, data analysis
    Physical characteristicsHost batteryBuilt-in high-capacity lithium battery 6800mAh/7.4V, network mobile station working time is more than 10 hours[2]
    External power supplySupport USB port charging and external power supply
    sizeΦ132mmx67mm
    weight≤0.82kg
    Power consumption4.2W
    materialThe shell is made of magnesium alloy material
    Environmental characteristicsDustproof and waterproofIP68
    Anti-fallResistance to natural drop of 2m high measuring rod
    Relative humidity100% non-condensing
    Operating temperature-30℃~+70℃
    storage temperature-40℃~+80℃


    Packaging & Shipping


    Economical 2


    Our Services

    1. Warranty: 12 months warranty is offered for survey equipment. 6 months warranty offered for survey accessory. Warranty comes in effective from the day your receive good.
    2. Repair in warranty: We are responsible for supplying new parts for repairing. Round way freight will be charged by us. If it is necessary, product will be required to send back to our service center to be repaired, round way freight is charged by us. Our engineer will repair in your office for special case.
    3. Repair out of warranty: We will offer related parts at commercial cost. Freight will be shared by us
    4. Training and calibration: Our engineer is qualified for training and calibration for GNSS and Total Station on site. We offer this service to bulk order while customer has requirement.
    5. Technical support is offered 24/365.
