    G970II High Accuracy GNSS GPS Surveying Equipment Rtk Unistrong

    Ask Lasest Price
    Brand Name : UniStrong
    Model Number : G970II Pro
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 10pcs/day
    Delivery Time : 5-10day
    • Product Details
    • Company Profile

    G970II High Accuracy GNSS GPS Surveying Equipment Rtk Unistrong

    Product Description

    New model high Accuracy Gnss Gps Surveying Equipment Rtk UniStrong G970II Pro price:


    G970II High Accuracy GNSS GPS Surveying Equipment Rtk UnistrongG970II High Accuracy GNSS GPS Surveying Equipment Rtk UnistrongG970II High Accuracy GNSS GPS Surveying Equipment Rtk UnistrongG970II High Accuracy GNSS GPS Surveying Equipment Rtk Unistrong

    Technical parameter
    ModelG970II-HG970II-TXG970II-NXG970II-HXG970II-ZX
    GNSSChannels394336555394394
    SignalsBDS: B1, B2, B3
    GPS: L1CA, L1P. L1C, L2P, L2C, L5
    GLOASS: G1,G2, P1, P2
    GALILEO: E1BC, E5a. E5b
    QZSS: L1CA. L2C. L5, L1C
    SBAS: L1CA, L5;
    L-Band
    AccuracyStaticH: 2.5 mm±1ppm , V: 5 mm±1ppm
    RTKH: 8 mm±1ppm, V:15 mm±1ppm
    DGNSS<0.5m
    ATLAS8cm//8cm8cm
    SystemInitialization Time8s
    Initialization Reliable99.90%
    Operating SystemLinux
    Merrory8GB, support expanable MisroSD
    Wifi802.11 b/g/n
    BluetoothV2.1+EDR/V4.1Dual,Class2
    E-Bubble/supportsupportsupportsupport
    Tilt Survey/support IMU Tilt Survey, no need calibrationIMU Tilt Survey 60°,Fusion Positioning/400Hz refresh rate
    DatalinkAudiosupport TTS audio broadcast
    UHFTx/Rx Internal Radio, 1W/2W adjustable
    Protocolsupport GeoTalk,SATEL,PCC-GMSK,TrimTalk,TrimMark,SOUTH
    Network4G-LTE, TE-SCDMA, CDMA(EVDO 2000), WCDMA, GSM(GPRS)
    PhysicalInterface1*TNC Radio Antenna, 1*5Pin(Power & RS232),1*7Pin (USB 81 RS232)
    Button1 Power Button
    Indication Light4 Indication Lights
    SizeΦ156mm * H 76mm
    Weight1.2kg
    Power supplyBattery capacity7.2V, 24.5Wh(standard two batteries)
    Life TimerStatic Survey: 15 hours, Rover RTK survey: 12h
    External power sourceDC 9-18V, with overvoltage protection
    EnvironmentWork Temporature-35℃ ~ +65℃
    Storage Temporature-55℃ ~ +80℃
    waterproof&dustproofIP67
    Humidity100% anti-condensation
