    4G Full Netcom CHC RTK Satellite System CHCNAV X11 Inertial Navigation RTK GNSS Receiver

    Ask Lasest Price
    Brand Name : CHCNAV
    Model Number : X11
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 10pcs/day
    Delivery Time : 5-10day
    • Product Details
    • Company Profile

    4G Full Netcom CHC RTK Satellite System CHCNAV X11 Inertial Navigation RTK GNSS Receiver

    Product Description

    4G full Netcom CHC RTK Satellite system CHCNAV X11 Inertial Navigation RTK GNSS Receiver :

    4G Full Netcom CHC RTK Satellite System CHCNAV X11 Inertial Navigation RTK GNSS Receiver4G Full Netcom CHC RTK Satellite System CHCNAV X11 Inertial Navigation RTK GNSS Receiver4G Full Netcom CHC RTK Satellite System CHCNAV X11 Inertial Navigation RTK GNSS Receiver


    Technical parameter
    projectcontentindex
    Satellites and Accuracysatellite systemGPS+BDS+Glonass+Galileo+QZSS, support the third generation of Beidou, support five-star twenty-one frequency
    number of channels1408
    Initialize reliability99.90%
    No network continued testSupport high-precision solution, the base station can publish data such as power information
    Signal capture sensitivityTypical value -162dbm, stronger ability to capture weak signal
    satellite-based differentialSupport L-Band function:
    (optional)Support Beidou third-generation B2b-ppp service, the accuracy can reach centimeter level
    Support domestic satellite-based enhanced services (centimeter level)
    Support ground-based augmentation system differential services (centimeter level)
    Global satellite-based centimeter-level services can be opened
    GNSS+Inertial Navigation[2]IMU update rate200Hz
    slope0-60 degrees
    super inertial navigationSupport travel process to complete initialization, and support centering rod calibration
    User interactionindicator light1 satellite light + 1 differential data light + 1 static indicator light + 1 power light
    buttonStatic toggle key + power/confirm key
    web pageSupport PC/mobile web pages
    CameraFunctionSupport visual stakeout
    pixel2MP
    frame rate25Hz
    Field of View (H, V)75°, 75°
    IlluminationStarlight-level camera, still maintains full-color picture under 0.01lux illumination
    physical propertiessizeΦ133mm*87.6mm
    weight0.8 Kg (including battery)
    materialmagnesium alloy
    Operating temperature-45ºC~+75ºC
    storage temperature-55ºC~+85ºC
    waterproof breathable membranePrevent water vapor from entering the equipment in harsh environments such as sun exposure and sudden heavy rain
    Waterproof and dustproofIP68 (Protection against 1 meter immersion in water for 30 minutes)
    anti-collisionIK08 (with the same mechanical impact force as a 2.5kg steel ram without damage, 3 meters drop resistance)
    Electrical propertiesBatteryBuilt-in 6600mAh lithium battery
    The typical battery life of the mobile station is more than 16h
    fast chargeSupport fast charge, up to 24w fast charge
    Built-in storage8GB, can support external expansion 128G, automatic cycle storage, disk
    After the storage is full, it will be automatically deleted, and the static data of the receiver will be copied with one key.
    data outputDifferential dataRTCM2.X, RTCM3.X, CMR, CHC516
    positioning dataNMEA-0183
    static dataHCN, RINEX 2.11, RINEX3.02
    data communicationwireless connectionSupport Wi-Fi data link
    network moduleHandbook supports 4G full Netcom
    radioBuilt-in single-receiver radio, support CTI/TT450/transparent transmission protocol
    Advanced FeaturesOne-click fixComes with a CORS account, which can be fixed at startup
    Smart serviceSupport CTI cloud service, provide cloud storage, function code sharing
    control handbookmodelHCE600 Android Measurement Handbook
    operating systemAndroid 10
    CPUOcta-core 2.0GHz processor
    network4G full Netcom, built-in eSIM for three years of surveying and mapping traffic
    Operating temperature-30ºC-+60ºC
    Storage temperature-40ºC-+80ºC
    Waterproof and dustproofIP68
    Packaging & Shipping


    Economical 2


    Our Services

    1. Warranty: 12 months warranty is offered for survey equipment. 6 months warranty offered for survey accessory. Warranty comes in effective from the day your receive good.
    2. Repair in warranty: We are responsible for supplying new parts for repairing. Round way freight will be charged by us. If it is necessary, product will be required to send back to our service center to be repaired, round way freight is charged by us. Our engineer will repair in your office for special case.
    3. Repair out of warranty: We will offer related parts at commercial cost. Freight will be shared by us
    4. Training and calibration: Our engineer is qualified for training and calibration for GNSS and Total Station on site. We offer this service to bulk order while customer has requirement.
    5. Technical support is offered 24/365.


    Company Information

    Shanghai Galxy International Trade company, Ltd. combining with developing, researching and producing. Our company is located in Pudong Developing Zone, and has two subsidiary companies: Shanghai Galaxy International Trade Co., Ltd. and Mato Opto-electrical High-tech Company. Our company has researching center and factory in Changzhou.

    Our main products are as following: total station, electronic theodolite, automatic level, laser level, rotation laser, GPS, distance laser sensor and accessories, such as tripod, prism, pole, staff and USB cable for total station. Our company designs software for many domestic and oversea factories, for example, Boif, TJOP, Stanley, and Cst-Berger. We have powerful capacity in technical research, and the products we designed have advanced technology and steady performance. The non-prism total station and the absolute coding measure instrument we developed and produced have very competitive points in the measure instrument market.

    We expect that we could cooperate with more business partners from all over the world. In addition, we can do OEM service for companies or dealers that want to find better producers in China.

    Our goal is to produce the best surveying instruments in the world.

    Our target is to globalize the market, internationalize the quality and maximize the profit!
    Economical 2

    FAQ

    1.What kind payment method we accept?
    T/T, L/C at sight, Western Union, Trade Assurance on Alibaba
    Note: Customer will be requested to pay 4% transaction fee upon total amount charged by EBAY.
    2.How can you guarantee payment safety ?
    Our company supports TRADE ASSURANCE service. If you will choose payment through ALIBABA TRADE ASSURANCE service, you payment will be guaranteed. Because we are not able to receive payment until you confirm goods receipt.

    3.What kinds of shipment for goods and how long time it takes ?
    Our company supports DHL, FEDEX, UPS, TNT, CHINA POST, by sea and other methods. Shipping time is 3-5 days from payment receipt.

    4.Does your company ship battery or not ?
    Our company can receive battery order and ship to customer normally, except a few special countries.

    5.Do you have other items not displayed on your website ?
    Yes, our company supplies full survey range products. If you are looking for product not displayed on our website. Please contact us freely. We will reply you on time.
