project	content	X11
Satellites and Accuracy	satellite system	GPS+BDS+Glonass+Galileo+QZSS, support the third generation of Beidou, support five-star twenty-one frequency
	number of channels	1408
	Initialize reliability	99.90%
	No network continued test	Support high-precision solution, the base station can publish data such as power information
	Signal capture sensitivity	Typical value -162dbm, stronger ability to capture weak signal
	satellite-based differential	Support L-Band function:
	(optional)	Support Beidou third-generation B2b-ppp service, the accuracy can reach centimeter level
		Support domestic satellite-based enhanced services (centimeter level)
		Support ground-based augmentation system differential services (centimeter level)
		Global satellite-based centimeter-level services can be opened
GNSS+Inertial Navigation[2]	IMU update rate	200Hz
	slope	0-60 degrees
	super inertial navigation	Support travel process to complete initialization, and support centering rod calibration
User interaction	indicator light	1 satellite light + 1 differential data light + 1 static indicator light + 1 power light
	button	Static toggle key + power/confirm key
	web page	Support PC/mobile web pages
Camera	Function	Support visual stakeout
	pixel	2MP
	frame rate	25Hz
	Field of View (H, V)	75°, 75°
	Illumination	Starlight-level camera, still maintains full-color picture under 0.01lux illumination
physical properties	size	Φ133mm*87.6mm
	weight	0.8 Kg (including battery)
	material	magnesium alloy
	Operating temperature	-45ºC~+75ºC
	storage temperature	-55ºC~+85ºC
	waterproof breathable membrane	Prevent water vapor from entering the equipment in harsh environments such as sun exposure and sudden heavy rain
	Waterproof and dustproof	IP68 (Protection against 1 meter immersion in water for 30 minutes)
	anti-collision	IK08 (with the same mechanical impact force as a 2.5kg steel ram without damage, 3 meters drop resistance)
Electrical properties	Battery	Built-in 6600mAh lithium battery
		The typical battery life of the mobile station is more than 16h
	fast charge	Support fast charge, up to 24w fast charge
	Built-in storage	8GB, can support external expansion 128G, automatic cycle storage, disk
		After the storage is full, it will be automatically deleted, and the static data of the receiver will be copied with one key.
data output	Differential data	RTCM2.X, RTCM3.X, CMR, CHC516
	positioning data	NMEA-0183
	static data	HCN, RINEX 2.11, RINEX3.02
data communication	wireless connection	Support Wi-Fi data link
	network module	Handbook supports 4G full Netcom
	radio	Built-in single-receiver radio, support CTI/TT450/transparent transmission protocol
Advanced Features	One-click fix	Comes with a CORS account, which can be fixed at startup
	Smart service	Support CTI cloud service, provide cloud storage, function code sharing
control handbook	model	HCE600 Android Measurement Handbook
	operating system	Android 10
	CPU	Octa-core 2.0GHz processor
	network	4G full Netcom, built-in eSIM for three years of surveying and mapping traffic
	Operating temperature	-30ºC-+60ºC
	Storage temperature	-40ºC-+80ºC
	Waterproof and dustproof	IP68

​
Packaging & ShippingWe can use the different international express company, usually, our first choice is DHL. if you have specified requirement , please inform us before the order.

Our Services
your inquiry will be replied within 24 hours, we welcome your email and call at any time.
our products are original and 100% new. and they will be carefully checked before we ship them out.
we provide one year quality warranty, within one year since you bought the products from us, you will get our technology support.
Company Information

Shanghai Galxy International Trade company, Ltd. combining with developing, researching and producing. Our company is located in Pudong Developing Zone, and has two subsidiary companies: Shanghai Galaxy International Trade Co., Ltd. and Mato Opto-electrical High-tech Company. Our company has researching center and factory in Changzhou.

Our main products are as following: total station, electronic theodolite, automatic level, laser level, rotation laser, GPS, distance laser sensor and accessories, such as tripod, prism, pole, staff and USB cable for total station. Our company designs software for many domestic and oversea factories, for example, Boif, TJOP, Stanley, and Cst-Berger. We have powerful capacity in technical research, and the products we designed have advanced technology and steady performance. The non-prism total station and the absolute coding measure instrument we developed and produced have very competitive points in the measure instrument market.

We expect that we could cooperate with more business partners from all over the world. In addition, we can do OEM service for companies or dealers that want to find better producers in China.

Our goal is to produce the best surveying instruments in the world.

Our target is to globalize the market, internationalize the quality and maximize the profit!
